Specifications
|
||
HAMMER
MODEL |
RH12 |
|
Outside
Diameter (mm) |
256 |
|
Effective
Lenght Without Bit |
1115 |
|
Weight
(kg) |
1200 |
|
Spanner
Flat-Across Flats (mm) |
303 |
|
Thread
Size (API REG) |
6
5/8 |
|
RH12-Air
Consumption at working pressure |
||||||
WORKING
PRESSURE |
AIR
CONSUMPTION |
|||||
PSI |
BAR
(kg/cm3) |
CFM |
M3/MIN |
Lt/SEC |
||
100 |
6.9 |
850 |
24.3 |
405 |
||
150 |
10.5 |
900 |
37.1 |
620 |
||
200 |
13.8 |
1100 |
48.6 |
810 |
||
250 |
17.2 |
1370 |
64.3 |
1070 |
||
300 |
20.7 |
1500 |
77.1 |
1280 |
||
Normal Lubrication Dosage-RH12 |
|
BENCH
DRILLING |
WATER
WELL DRILLING |
3.0 Lt/Hr |
4.0
Lt/Hr |
