| Specifications | |
HAMMER
MODEL |
RH3 |
Outside
Diameter (mm) |
80 |
Effective
Lenght Without Bit |
761 |
Weight
(kg) |
19 |
Spanner
Flat-Across Flats (mm) |
64 |
Thread
Size (API REG) |
2
3/8 |
RH3-Air
Consumption at working pressure |
||||||||
| WORKING PRESSURE | AIR CONSUMPTION | |||||||
| PSI | BAR (kg/cm3) | CFM | M3/MIN | Lt/SEC | ||||
| 85 | 6 | 100 | 2.8 | 45 | ||||
| 150 | 10.5 | 120 | 3.4 | 57 | ||||
| 200 | 13.8 | 280 | 8.0 | 133 | ||||
| 250 | 17.2 | 365 EST | 10.4 EST | 175 EST | ||||
Normal Lubrication Dosage-RH3 |
|
BENCH
DRILLING |
WATER
WELL DRILLING |
0.3 Lt/Hr |
0.4
Lt/Hr |
