Specifications
|
||
HAMMER
MODEL |
RH3 |
|
Outside
Diameter (mm) |
80 |
|
Effective
Lenght Without Bit |
731 |
|
Weight
(kg) |
20 |
|
Spanner
Flat-Across Flats (mm) |
64 |
|
Thread
Size (API REG) |
2
3/8 |
|
RH3-Air
Consumption at working pressure |
||||||
WORKING
PRESSURE |
AIR
CONSUMPTION |
|||||
PSI |
BAR
(kg/cm3) |
CFM |
M3/MIN |
Lt/SEC |
||
85 |
6 |
100 |
2.8 |
45 |
||
150 |
10.5 |
120 |
3.4 |
57 |
||
200 |
13.8 |
280 |
8.0 |
133 |
||
250 |
17.2 |
365
EST |
10.4
EST |
175
EST |
||
Normal Lubrication Dosage-RH3 |
|
BENCH
DRILLING |
WATER
WELL DRILLING |
0.3 Lt/Hr |
0.4
Lt/Hr |
