| Specifications | ||
HAMMER
MODEL |
RH4 |
|
Outside
Diameter (mm) |
96 |
|
Effective
Lenght Without Bit |
768 |
|
Weight
(kg) |
29 |
|
Spanner
Flat-Across Flats (mm) |
76 |
|
Thread
Size (API REG) |
2
3/8 |
|
RH4-Air
Consumption at working pressure |
||||||||
| WORKING PRESSURE | AIR CONSUMPTION | |||||||
| PSI | BAR (kg/cm3) | CFM | M3/MIN | Lt/SEC | ||||
| 150 | 10.5 | 195 | 5.5 | 92 | ||||
| 200 | 13.8 | 260 | 7.4 | 123 | ||||
| 250 | 17.2 | 320 | 19.1 | 152 | ||||
| 300 | 20.7 | 390 | 11.1 | 185 | ||||
| 350 | 24.1 | 470 | 13.4 | 223 | ||||
Normal Lubrication Dosage-RH4 |
|
BENCH
DRILLING |
WATER
WELL DRILLING |
0.7 Lt/Hr |
0.1
Lt/Hr |
