Specifications
|
||
HAMMER
MODEL |
RH4 |
|
Outside
Diameter (mm) |
96 |
|
Effective
Lenght Without Bit |
818 |
|
Weight
(kg) |
31 |
|
Spanner
Flat-Across Flats (mm) |
76 |
|
Thread
Size (API REG) |
2
3/8 |
|
RH4-Air
Consumption at working pressure |
||||||||
WORKING
PRESSURE |
AIR
CONSUMPTION |
|||||||
PSI |
BAR
(kg/cm3) |
CFM |
M3/MIN |
Lt/SEC |
||||
150 |
10.5 |
195 |
5.5 |
92 |
||||
200 |
13.8 |
260 |
7.4 |
123 |
||||
250 |
17.2 |
320 |
19.1 |
152 |
||||
300 |
20.7 |
390 |
11.1 |
185 |
||||
350 |
24.1 |
470 |
13.4 |
223 |
||||
Normal
Lubrication Dosage-RH4 |
|
BENCH
DRILLING |
WATER
WELL DRILLING
|
0.7 Lt/Hr |
1.0
Lt/Hr
|
