| Specifications | ||
HAMMER
MODEL |
RH5 |
|
Outside
Diameter (mm) |
116 |
|
Effective
Lenght Without Bit |
902 |
|
Weight
(kg) |
49.5 |
|
Spanner
Flat-Across Flats (mm) |
89 |
|
Thread
Size (API REG) |
3
1/2 |
|
RH5-Air
Consumption at working pressure |
||||||||
| WORKING PRESSURE | AIR CONSUMPTION | |||||||
| PSI | BAR (kg/cm3) | CFM | M3/MIN | Lt/SEC | ||||
| 150 | 10.5 | 280 | 8.0 | 133 | ||||
| 200 | 13.8 | 400 | 11.4 | 190 | ||||
| 250 | 17.2 | 550 | 15.7 | 262 | ||||
| 300 | 20.7 | 680 | 19.4 | 323 | ||||
| 350 | 24.1 | 790 | 22.6 | 376 | ||||
Normal Lubrication Dosage-RH5 |
|
BENCH
DRILLING |
WATER
WELL DRILLING |
0.8 Lt/Hr |
1.2
Lt/Hr |
