Specifications
|
||
HAMMER
MODEL |
RH5 |
|
Outside
Diameter (mm) |
116 |
|
Effective
Lenght Without Bit |
902 |
|
Weight
(kg) |
49.5 |
|
Spanner
Flat-Across Flats (mm) |
89 |
|
Thread
Size (API REG) |
3
1/2 |
|
RH5-Air
Consumption at working pressure |
||||||||
WORKING
PRESSURE |
AIR
CONSUMPTION |
|||||||
PSI |
BAR
(kg/cm3) |
CFM |
M3/MIN |
Lt/SEC |
||||
150 |
10.5 |
280 |
8.0 |
133 |
||||
200 |
13.8 |
400 |
11.4 |
190 |
||||
250 |
17.2 |
550 |
15.7 |
262 |
||||
300 |
20.7 |
680 |
19.4 |
323 |
||||
350 |
24.1 |
790 |
22.6 |
376 |
||||
Normal
Lubrication Dosage-RH5 |
||
BENCH
DRILLING |
WATER
WELL DRILLING |
|
0.8 Lt/Hr |
1.2
Lt/Hr |
|
