Specifications
|
||
HAMMER
MODEL |
RH6 |
|
Outside
Diameter (mm) Standard |
140 |
|
Outside
Diameter (mm) Heavy Duty |
145 |
|
Effective
Lenght Without Bit |
976 |
|
Weight
(kg) |
78 |
|
Weight
(kg) Heavy Duty |
85 |
|
Spanner
Flat-Across Flats (mm) |
114 |
|
Thread
Size (API REG) |
3
1/2 |
|
RH6-Air
Consumption at working pressure |
||||||||
WORKING
PRESSURE |
AIR
CONSUMPTION |
|||||||
PSI |
BAR
(kg/cm3) |
CFM |
M3/MIN |
Lt/SEC |
||||
150 |
10.5 |
400 |
11.4 |
190 |
||||
200 |
13.8 |
580 |
16.6 |
277 |
||||
250 |
17.2 |
700 |
20.0 |
333 |
||||
300 |
20.7 |
820 |
24.8 |
413 |
||||
350 |
24.1 |
900 |
28.6 |
476 |
||||
Normal
Lubrication Dosage-RH6 |
|
BENCH
DRILLING |
WATER
WELL DRILLING |
1 Lt/Hr |
1.5
Lt/Hr |
